J Series

Ballistic & Forced Entry Grade Sub-framing

J SERIES | SUBFRAMING

Riot Glass® J Series sub-framing is available in ballistic and forced entry grades and designed to provide a smooth, even surface for mounting our secondary glazing systems.
Also referred to as our Compression Framing System, the J Series can be made with our patented compression technology for mounting into historic structures without drilling or other permanent damage to the building’s original materials. It can be removed at a later date with no signs of having been installed.

The J Series is custom-made to the dimensions of each individual window opening. Acting as an exoskeleton, the J Series provides a suitable structure to which we can attach our AP and RG Series retrofitted systems.

The J Series meets ASTM F 3038 forced entry testing for 15 minutes. It is only required when existing framing conditions are not conducive to retrofit. Examples may include damaged or uneven existing framing, buildings with historic significance, or other limiting factors. Learn more about our ASTM F 3038 test results here.

The J Series can be manufactured as a standalone product or as a foundation for our ArmorPlast Gen II framing when required to provide a smooth, stable mounting surface.

THREE LEVELS OF PROTECTION | YOU’RE BUYING TIME

30 Sec – 1 Minute

Security film’s time delay is comparable to
scissor gates, bars, and roll-down shutters

GOOD
armorplast authorized dealer logo

AP25 Access Denial

No Entry

BETTER
riot glass authorized dealer logoarmorplast authorized dealer logo

No Entry + Bullet Resistant

BEST

Frequently Asked questions

What sizes are available?
Riot Glass® (RG) and ArmorPlast® (AP) are available in maximum sizes 72″ x 120″. If window openings exceed that size, we simply reconfigure the mullions using our AP Series support mullions specifically designed to accommodate our AP and RG Framing. RG Security Laminates (our exclusive line of security window film) is available in 72″ maximum widths at any length.
Will it look like my existing glass?
Riot Glass®, ArmorPlast®, and RG Security Laminates all look like regular glass. Depending on the thickness, visual acuity can be slightly affected, but overall you won’t see a distinguishable difference. Yellowing is not a concern and is covered by the warranty. For added safety, all three products allow police and patrol services to see inside your property. Privacy tints are available as an option in most Riot Glass® products.
How do I clean and care for security glass?
Traditional cleaning methods work on all types of Riot Glass® security glass and laminates. All of our security glass products have a protective outer layer to avoid scratching and marring. The process is similar to caring for a new car. You put it through all kinds of paces every day, but you do so with care and attention to detail. Treat security glass the way you would the finish on a fine automobile and you’ll enjoy years of trouble-free service. Always follow the cleaning instructions that come with your Riot Glass® purchases for optimal product longevity.
What is the warranty on the glass and framing?
Warranties vary by product and can also change depending on the application. In some cases, our products carry a limited lifetime warranty, while others are protected for up to 15 years. Your security specialist will provide details on both warranty coverage and life expectancy for your specific product needs.
How do I know it will work?
All of our products have been thoroughly tested in highly accredited laboratory settings and, more importantly, in real-world situations. While there are no ironclad guarantees, every retail store, commercial building, and school needs some level of security glass protection. Security glazing products are designed to delay and deter, and in many cases are the determining factor between life and death.
What happens during a site inspection?
Our security specialists will do a complete threat assessment, discuss your goals, and provide a detailed, easy-to-read proposal. We will also measure your windows and frames, then evaluate the overall condition and retrofit adaptability to determine the best solution for your property.
Do I need to remove signage and graphics?
It depends on which product you select and where the graphics are displayed. During the site inspection, our expert security consultant will advise whether graphics must be removed and replaced or stay intact.
What is UL 752? What’s the difference between ballistic and non-ballistic ratings?
Underwriters Laboratories™ offers multiple ballistic rating levels. Designed to measure bullet resistance, ballistic ratings factor in the grain (weight), caliber, and velocity of the ammunition. Non-ballistic (containment grade) products allow bullet penetration, but won’t break down or appreciably diminish in strength. In other words, the bullets leave holes, but the panels remain intact, keeping intruders out of the building.
